Place of Origin:
China
Brand Name:
Tieke
Model Number:
NX100
Brief introduction:
100 Tons steel slag transport wagon is specially designed to transport steel slag tank in steel making factories. It is low speed heavy load workshop materials transfer rail wagons.
We have designed and manufactured various railway iron ladle transfer wagons, steel slag transport wagons, KPT electric self-driven flat wagons for workshop railway transport application.
Main features:
Main technical parameters:
| Name | 100T Steel Slag Transport Wagon |
| Load | 100t |
| Tare weight | 31t |
| Axle load | 35t |
| Commercial running speed | 35km/h |
| Wagon length | 11500mm |
| Wagon’s max. width | 3000mm |
| Coupler center’s height | 880mm |
| Bogie | 80-1 three piece casting bogie |
| Wheel diameter | 841mm |
| Min radius | 75m |
Package and delivery:
Nude pack with support base and with anti-collision protection.
Detail export packing design will be designed according to destination port's lifting capability and destination transportation condition.
FAQ:
Q1: Are you a trading company or a factory?
A: We are directly a factory and we manufacture and export railway wagons directly.
Q2: Do you have design ability to provide customized railway vehicles?
A: Yes, we have professional technical team and we are familiar with international railway standards like UIC, AAR, EN and we are able to provide railway equipment according to customer requirements.
Q3: Chinese railway gauge is 1435mm, but our country’s is 1000mm gauge, will this be a problem for you?
A: Of course not, we are able to design railway wagons of different gauges like 1435mm, 1000mm, 1067mm, 1520mm or other required railway gauges.
Q4: Why should I choose you, compared with your competitors?
A: Tieke Railway was transformed from wagons factory belong to Chinese Railway in 2016 and the company have over 10 years’ experiences in manufacturing railway wagons; Now as Tieke Railway is a private company and adopt modern market management strategies, our services are flexible and more considerate and our cost is more controllable.
Q5: What should I provide to get a quotation from you?
A: You could send your inquiry with detail drawings, product photos, detail technical parameters or requirement description. A complete requirement input is very important for us to provide an accurate quotation to you.
